Description
The 1999 Ingersoll-Rand DD-24 is a compact double drum vibratory roller built for asphalt compaction on parking lots, driveways, bike paths, and small road projects. Its tandem-drum design delivers uniform compaction in a maneuverable footprint, making it a go-to machine for patching, overlay work, and finish rolling.
Powered by a Deutz 3-cylinder diesel engine, the DD-24 provides reliable, fuel-efficient performance with simple maintenance requirements. This unit is well-suited for small to mid-size paving crews that need a dependable compaction roller without the overhead of a full-size machine.
Specifications
- Engine: Deutz F3L1011F, 3-Cylinder Diesel
- Horsepower: 32 HP (24 kW)
- Operating Weight: 5,725 lbs (2,597 kg)
- Drum Width: 47.3 in (1,201 mm)
- Drum Diameter: 27.6 in (701 mm)
- Vibration Frequency: 55 / 67 Hz
- Centrifugal Force: 8,992 / 6,295 lbs (40 / 28 kN)
- Amplitude: 0.1 in (0.25 mm)
- Max Travel Speed: 6.3 mph (10.1 km/h)
- Fuel Capacity: 10.6 gal (40 L)
- Water Tank Capacity: 7.1 gal (27 L)
Need to know if this roller meets your compaction standards?
